Mains Dimmed Driver 20W Constant Current (300-650mA)

To be able to purchase products from us, you need to have a trade account.

Mains Leading/Trailing Edge TRIAC dimmable driver.

Ideal for powering and dimming constant current LED lighting in the range of 200-900mA DC via Leading/Trailing edge mains dimming.

This driver steps down a Leading/Trailing edge mains dimmed voltage (200-240V AC) to between 10V and 42V DC at a constant current. It PWM dims the output according to the dimmer switch. The input and output is via screw terminals on the sides of the unit.

Simply select the output current ‘on installation’ using Dip switches on the end of the driver. Select from: 200mA, 300mA, 400mA, 500mA, 600mA, 700mA, 800mA, 900mA.

£23.08
£19.23excluding VAT

Quantity Discount Per Item Price
10-24 5% £18.27
25-49 10% £17.31
50-99 15% £16.35
100-199 20% £15.38
200+ 25% £14.42
SKU: SE-20-300-650-G1T Categories: ,

Specification

Dimmable Driver

Dimming interface Leading/Trailing Edge TRIAC
Dimming range 0-100%
Input voltage 200-240VAC
Efficiency >83%
Output voltage 10-42VDC (varies – see full data sheet)
Output power 2-25W
Output current Selected by DIP switch: 300mA, 350mA, 400mA, 450mA, 500mA, 550mA, 600mA, 650mA
Dimension (mm) 127L 43W 30H

Download Data Sheet

Description

Package Contents

  • SE-20-300-650-G1T Driver

Additional information

Weight 0.3 kg
Output Current

200mA, 300mA, 400mA, 500mA, 600mA, 700mA, 800mA, 900mA
